Future-Proof Waste Conveyance for a Mixed-Use Development
Marina View Residences is a mixed-use development in Singapore’s District 01, comprising 683 residential units atop commercial facilities. Slated for completion in 2029, the project required an efficient refuse handling solution.
Instead of traditional multiple bin centers and frequent pickups, the development integrates an advanced automated waste collection system. A two-fraction stationary AIRWASTE system will serve the residential tower, while a high-capacity dust-screw compactor handles commercial waste.
Implementation Approach
A 2-fraction pneumatic Automated Waste Collection System (AWCS) is implemented for the residential component. The two-fraction design allows for waste segregation using controlled diverter valves, so each waste type is directed into separate containers
For the commercial strata, the solution provides a dedicated stationary dust-screw compactor system. Collected waste from the commercial premises is deposited into this sealed tank via a bin-lifting mechanism.
This setup allows the commercial waste stream to be managed independently of the residential AWCS.
Crucially, the entire system has been engineered with future-ready features and site-specific constraints in mind. To tackle limited headroom, the internal conveyance pipes are sized at 406 mm diameter, enabling installation within tight ceiling voids.
At the same time, the main horizontal pipe run is designed to transition up to a 508 mm diameter at the point of connection to external infrastructure, ensuring compatibility with any future-planned District Pneumatic Waste Conveyance System (DPWCS).
The system design applied dual pipe sizing, supported by flexible joints and vibration isolation to minimise structural noise. Triple diverter valves were strategically placed to manage waste and recyclables efficiently, while enabling sectional isolation for maintenance.
For commercial areas, a 16 m³ dust-screw compactor with modular adaptability was installed, allowing high-volume waste handling with minimal disruption.
Together, these measures provide a robust and adaptable framework that balances operational efficiency with maintainability.
“By combining dual pipe sizing, vibration isolation, and diverter valve controls, Marina View’s system not only meets today’s needs but is already engineered for tomorrow’s district-scale integration.”
In summary
Highlights
In summary
Highlights
Expertise in complex PWCS Projects
Marina View Residences demonstrates a balanced, future-proof waste solution for mixed-use high-rises. The combination of pneumatic conveyance for residents and a dust-screw system for commercial spaces ensures efficiency, hygiene, and operational flexibility.
Designed for seamless DPWCS integration, the system represents a forward-looking model for sustainable urban developments in Singapore.
